FAG 23026-E1A-XL-M-C4
Price: 345.42 $
Specifications
| Brand | FAG |
| Item Number | 23026-E1A-XL-M-C4 FAG |
| Manufacturer Part Number | 0167064630040 |
| Also known as |
23026-E1A-M-C4 |
| EAN | 4026677863577 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 130 |
| Outer (D) MM | 200 |
| Width (B) MM | 52 |
| Inner (d) Inch | 5.1181 |
| Outer (D) Inch | 7.874 |
| Width (B) Inch | 2.0472 |
| Weight (kg) | 5.83 kg |
| Bore | C - Cylindrical Bore |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| Radial Internal Play | C4 Internal Play (Higher than C3) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Width (b) mm | 52 |
| Radial Static Load Rating C0r (N) | 730000 |
| Radial Dynamic Load Rating Cr (N) | 540000 |
| Basic static load rating, radial (C 0r) | "730000.0000" |
| Limiting speed (n G) | 3600 |
| Reference speed (n u03d1r) | 2600 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 230..-E1A, main dimensions to DIN 635-2 |
| E1 | Increased Capacity Design |
| A | Modified Internal Construction |
| XL | X-Life |
| M | Solid Brass Cage, Guided By Rollers |
| C4 | Bearing Internal Clearance Greater Than C3 |
