FAG 22320-E1A-XL-M-C4
Price: 511.76 $
Specifications
| Brand | FAG |
| Item Number | 22320-E1A-XL-M-C4 FAG |
| Manufacturer Part Number | 0190212670040 |
| Also known as |
22320-E1A-M-C4 |
| EAN | 4026677861955 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 100 |
| Outer (D) MM | 215 |
| Width (B) MM | 73 |
| Inner (d) Inch | 3.937 |
| Outer (D) Inch | 8.4646 |
| Width (B) Inch | 2.874 |
| Weight (kg) | 12.8 kg |
| Bore | C - Cylindrical Bore |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| Radial Internal Play | C4 Internal Play (Higher than C3) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Width (b) mm | 73 |
| Radial Static Load Rating C0r (N) | 920000 |
| Radial Dynamic Load Rating Cr (N) | 810000 |
| Basic static load rating, radial (C 0r) | "920000.0000" |
| Limiting speed (n G) | 3300 |
| Reference speed (n u03d1r) | 2380 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearing 223..-E1A-XL-M, symmetric 2 outer ribs |
| E1 | Increased Capacity Design |
| A | Modified Internal Construction |
| XL | X-Life |
| M | Solid Brass Cage, Guided By Rollers |
| C4 | Bearing Internal Clearance Greater Than C3 |
