FAG 22319-E1-XL-K-T41A
Price: 384.51 $
Specifications
| Brand | FAG |
| Item Number | 22319-E1-XL-K-T41A FAG |
| Manufacturer Part Number | 0190211940000 |
| Also known as |
22319-E1-K-T41A |
| EAN | 4026677870780 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 95 |
| Outer (D) MM | 200 |
| Width (B) MM | 67 |
| Inner (d) Inch | 3.7402 |
| Outer (D) Inch | 7.874 |
| Width (B) Inch | 2.6378 |
| Weight (kg) | 9.36 kg |
| Bore | K - 1:12 Tapered Bore (Standard for Most Types) |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | S - Steel or Standard Cage |
| Radial Internal Play | C4 Internal Play (Higher than C3) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Vibrating Screen Execution |
| Width (b) mm | 67 |
| Radial Static Load Rating C0r (N) | 700000 |
| Radial Dynamic Load Rating Cr (N) | 670000 |
| Limiting speed (n G) | 3700 |
| Reference speed (n u03d1r) | 2800 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 223..-E1-K-T41A, For oscillating load with restricted diameter tolerances, with tapered bore |
| E1 | Increased Capacity Design |
| XL | X-Life |
| K | Tapered Bore, Taper 1:12 |
| T41A | Spherical Roller Bearings For Vibrating Screens (C4 Clearance), Old Designation is C4.F80 |
