FAG 22205-E1-XL-K-C3

FAG 22205-E1-XL-K-C3
FAG 22205-E1-XL-K-C3 rulman resim 1
FAG 22205-E1-XL-K-C3 rulman resim 2
FAG 22205-E1-XL-K-C3 rulman resim 3
FAG 22205-E1-XL-K-C3 rulman resim 4
FAG 22205-E1-XL-K-C3 rulman resim 5
FAG 22205-E1-XL-K-C3 rulman resim 6
Price: 46.13 $
Specifications
Brand FAG
Item Number 22205-E1-XL-K-C3 FAG
Manufacturer Part Number 0190003160030
Also known as 22205-E1-K-C3
EAN 4026677808066
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 52
Width (B) MM 18
Inner (d) Inch 0.9843
Outer (D) Inch 2.0472
Width (B) Inch 0.7087
Weight (kg) 0.164 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type S - Steel or Standard Cage
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 18
Radial Static Load Rating C0r (N) 42500
Radial Dynamic Load Rating Cr (N) 48500
Basic static load rating, radial (C 0r) "42500.0000"
Limiting speed (n G) 14400
Reference speed (n u03d1r) 9200
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 222..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Suffix description
E1 Increased Capacity Design
XL X-Life
K Tapered Bore, Taper 1:12
C3 Internal Clearance Larger Than Normal
