FAG 21320-E1-XL-TVPB

FAG 21320-E1-XL-TVPB
FAG 21320-E1-XL-TVPB rulman resim 1
FAG 21320-E1-XL-TVPB rulman resim 2
FAG 21320-E1-XL-TVPB rulman resim 3
FAG 21320-E1-XL-TVPB rulman resim 4
FAG 21320-E1-XL-TVPB rulman resim 5
FAG 21320-E1-XL-TVPB rulman resim 6
Price: 315.19 $
Specifications
Brand FAG
Item Number 21320-E1-XL-TVPB FAG
Manufacturer Part Number 0190149610000
Also known as 21320-E1-TVPB
EAN 4026677832191
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 100
Outer (D) MM 215
Width (B) MM 47
Inner (d) Inch 3.937
Outer (D) Inch 8.4646
Width (B) Inch 1.8504
Weight (kg) 8.19 kg
Product Properties
Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 47
Radial Static Load Rating C0r (N) 530000
Radial Dynamic Load Rating Cr (N) 495000
Basic static load rating, radial (C 0r) "530000.0000"
Limiting speed (n G) 4400
Reference speed (n u03d1r) 3050
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
